Cash drawer MDX32

*plus VAT

• The ideal drawer for checkout areas with small footprints and the optimal base for touchscreen checkouts
• Coin tray with 8 calibrated coin cups
• Banknote insert with 6 slanted bill compartments
• 2 additional universal compartments, e.g. for roll money and receipts
• Removable cash tray with lockable lid
• Drawer guide via ball bearing runners
• Keyed alike 3-position cylinder lock
• Rugged all steel construction
• Surface-mounted and under-mounted cash drawer through pre-punched mounting holes on the top of the housing

Delivery within 1-2 working days

• Details
• Technical data
• Scope of delivery

• Installation:
  The cash drawer can be mounted on or under the counter.

  Micro switch:
  A microswitch for status query is integrated.

  Electrical connection options:
  Compatible with all systems.

  Connection cable:
  Separate, plugged 2 m cable on RJ11/RJ12 as standard. (Other systems possible on request)

  Lock on the cash drawer:
  Keyed alike 3-position cylinder lock (emergency opening, electr. operation, locked). including 2 keys with 150 locking variants optional.

  Cash tray with lockable lid:
  Lid with 2-position cylinder lock including 2 keys.

• Color: black gray / anthracite (RAL 7021)

  Weight: 18.1 kg

  Voltage: 24 V (12 V on request)

  Width: 330 mm

  Height: 130 mm

  Depth: 420 mm

  Item number: 29101.020-0020

• • MDX 32 cash drawer (black gray/anthracite, RAL 7021)
  • Separate, plugged 2 m cable to RJ11/RJ12
  • 8 weighable coin cups
  • Removable money insert
  • Lockable lid for the money insert
  • 2 keys for 3-position cylinder lock and the cover lock (same lock).
